Block Ice Machine
FIB-180 This FIB-180 is our new concept of direct ice block system instead of traditional brine based system, after invest & study so many years of fields trips around the world. We found that to design the new tech direct cooling ice block ice machine is quote popular among customers. From discussion with clients, customer has a high requirements for block ice quality. however, this direct cooling type is able to produce etable block ice if water is clean enough. and it saves ice making time, ice doffing time, save labor, many advantages.
This innovative direct cooling or we can called direct refrigeration or direct freezing block ice machine using aluminum freezing plates. The material is completely conforms to food standards. If the water supply is fresh water or clean, then the block ice produced by this direct cooling type can be eaten directly, and of course it can also be used for foodstuffs cooling, fish cooling, etc. Our engineer go all over the world to help you to install & commission our block ice plant after you bought from us. Like in India, Canada, middle east, South Africa, the Philippines, Brazil, England, and Australia.
Below is main specification of this 26tons daily direct cooling block ice plant Power supply:380V/3P/50Hz Refrigerant:R404A/R22 Weight of each block ice:50kg/25KG Cooling mode: evaporative cooling Ice doffing time: within 30 hours Need person to operate: 1 or 2 person to assist, it’s automatic, Compressor brand: Germany Bitzer Solenoid Valve brand: Denmark Danfoss Programmable logic controller: Germany Siemens (tailor-made performance) Electric parts brand: France Schneider Other models:
( If you are interested in this model, you could contact us further for details. But all our machines are tailor-made, our engineer will design layouts according to your actual requirements & your local conditions, like power supply, temperature conditions, applicable refrigerant , etc. ) Block Ice Machine Work conditions: 1 All-in-one refrigeration systems. 2 Specially-designed Evaporator
, aluminum freezing plate, conforms to food standards. 3 Clean and sanitary block ice, suitable for human consumption. 4. Also can be used for cooling, fish cooling ,etc. 5 The refrigerant can be used globally, in line with national and international standards. 6 PLC controls and self-protects from breakdowns during water filling, ice making and harvesting. 7 Production capacity: 1tons to 18tons (if you choose non-containerized, no limitation about the largest capacity) with block ice weight of 5kg, 10kg, 15kg, 20kg, 25kg and 50kg) 8. Pneumatic crawler conveying system, maximizing the protection to the ice blocks during harvesting. 9. Bitzer compressor offers abundant compressing power and guaranteed producing ice in the shortest period with less energy consumption 10. Module design, the whole set consists of machine unit module, evaporator module, and cooling tower module; easy to ship and install; evaporator module can contain several parts in terms of capacity.
Dear friend, don't hesitate to give a call if you are interested! We would be very glad to be on service for you, as the most professional ice machine manufacturer with the biggest factory base in China, we are pleased to attach our best offer. We are definitely to contact you within 3 days after getting your inquiry. Other products: Ice Storage:
Direct refrigeration block ice machine technical parameter
|Model ||Capacity ||Refrigerant ||Electricity consumption ||Installment power ||Operating weight ||Dimension |
|-- ||Ton/D ||-- ||Kw ||Kw ||Kg ||mm |
|FIB-05D ||0.5 ||R22/R404A ||2.055 ||2.5 ||560 ||1500×800×1800 |
|FIB-10D ||1.0 ||R22/R404A ||4.850 ||6.0 ||960 ||1800×1200×2000 |
|FIB-15D ||1.5 ||R22/R404A ||6.940 ||8.5 ||1260 ||2800×1200×2000 |
|FIB-20D ||2.0 ||R22/R404A ||8.160 ||10.0 ||1460 ||2800×1400×2000 |
|FIB-25D ||2.5 ||R22/R404A ||9.510 ||12.0 ||1660 ||3200×1400×2000 |
|FIB-30D ||3.0 ||R22/R404A ||11.520 ||14.0 ||2180 ||3600×1400×2200 |
|FIB-35D ||3.5 ||R22/R404A ||14.850 ||18.0 ||2100 ||3600×1650×2000 |
|FIB-50D ||5.0 ||R22/R404A ||20.900 ||25.0 ||Unit:960 ||L1400×W1000×H1250 |
|Evaporator:2860 ||L4800×W1000×H2250 |
|Cooling tower:670 ||1380×H2170 |
|FIB-100D ||10.0 ||R22/R404A ||33.980 ||50.0 ||Unit:1680 ||L1800×W1000×H1450 |
|Evaporator:2860×2 ||L4800×W1000×H2250 |
|Cooling tower:670 ||2000×H2410 |
|FIB-150D ||15.0 ||R22/R404A ||59.150 ||75.0 ||Unit:2160 ||L2000×W1200×H1600 |
|Evaporator:2860×3 ||L4800×W1000×H2250 |
|Cooling tower:1120 ||2175×H2565 |
|FIB-200D ||20.0 ||R22/R404A ||85.550 ||105.0 ||Unit:2896 ||L2400×W1600×H1800 |
|Evaporator:2860×4 ||L4800×W1000×H2250 |
|Cooling tower:1300 ||2650×H2645 |
|FIB-250D ||25.0 ||R22/R404A ||94.050 ||120.0 ||Unit:3260 ||L3200×W1800×H2200 |
|Evaporator:2860×5 ||L4800×W1000×H2250 |
|Cooling tower:1630 ||3050×H2780 |
|FIB-300D ||30.0 ||R22/R404A ||113.550 ||150.0 ||Unit:3500 ||L3000×W2000×H2200 |
|Evaporator:2860×6 ||L4800×W1000×H2250 |
|Cooling tower:2730 ||3300×H2785 |
|Standard condition: Dry ball temperature is 33 ℃ and water inlet temperature is 20℃.|
