Fishery aquatic ice block/food cooling/Direct System Block Ice machine
Product Description
Weight (kg/block) | Dimension (L*W*H mm) |
---|---|
5 | 120×100×460 |
10 | 155×100×700 |
15 | 185×125×700 |
20 | 245×125×700 |
25 | 315×125×700 |
50 | 480×160×700 |
Model | Capacity | Refrigerant | Electricity consumption | Installment power | Operating weight | Dimension |
---|---|---|---|---|---|---|
-- | Ton/D | -- | Kw | Kw | Kg | mm |
FIB-05 | 0.5 | R22/R404A | 2.055 | 2.5 | 560 | 1500×800×1800 |
FIB-10 | 1.0 | R22/R404A | 4.850 | 6.0 | 960 | 1800×1200×2000 |
FIB-15 | 1.5 | R22/R404A | 6.940 | 8.5 | 1260 | 2800×1200×2000 |
FIB-20 | 2.0 | R22/R404A | 8.160 | 10.0 | 1460 | 2800×1400×2000 |
FIB-25 | 2.5 | R22/R404A | 9.510 | 12.0 | 1660 | 3200×1400×2000 |
FIB-30 | 3.0 | R22/R404A | 11.520 | 14.0 | 2180 | 3600×1400×2200 |
FIB-35 | 3.5 | R22/R404A | 14.850 | 18.0 | 2100 | 3600×1650×2000 |
FIB-50 | 5.0 | R22/R404A | 20.900 | 25.0 | Unit | L1400×W1000×H1250 |
Evaporator | L4800×W1000×H2250 | |||||
Cooling tower | 1380×H2170 | |||||
FIB-100 | 10.0 | R22/R404A | 33.980 | 50.0 | Unit:1680 | L1800×W1000×H1450 |
Evaporator: 2860×2 | L4800×W1000×H2250 | |||||
Cooling tower: 670 | 2000×H2410 | |||||
FIB-150 | 15.0 | R22/R404A | 59.150 | 75.0 | Unit:2160 | L2000×W1200×H1600 |
Evaporator: 2860×3 | L4800×W1000×H2250 | |||||
Cooling tower:1120 | 2175×H2565 | |||||
FIB-200 | 20.0 | R22/R404A | 85.550 | 105.0 | Unit:2896 | L2400×W1600×H1800 |
Evaporator: 2860×4 | L4800×W1000×H2250 | |||||
Cooling tower:1300 | 2650×H2645 | |||||
FIB-250 | 25.0 | R22/R404A | 94.050 | 120.0 | Unit:3260 | L3200×W1800×H2200 |
Evaporator: 2860×5 | L4800×W1000×H2250 | |||||
Cooling tower: 1630 | 3050×H2780 | |||||
FIB-300 | 30.0 | R22/R404A | 113.550 | 150.0 | Unit:3500 | L3000×W2000×H2200 |
Evaporator: 2860×6 | L4800×W1000×H2250 | |||||
Cooling tower: 2730 | 3300×H2785 | |||||
Standard condition: Dry ball temperature is 33 ℃ and water inlet temperature is 20℃. |
Perfect service system:
All Focusun ice machines come out with 15 months full warranty. If the machine breaks down in 15 months. Focusun will send the parts for free, even send the technician over if situation needed. When beyond the warranty, Focusun will supply the parts and service only for factory cost. | |
Process: | Please provide the copy of Sales Contract and describe the problems appeared. |
Problems confrimation: | |
Slight problem: | Please send the proof to our After-Sales Department, we will reply within two days. |
Serious problem: |
|
A | We will dispatch our Quality and Problems Appraisers to make a confirmation. |
B | Have a negotiation of the compensation and sign agreements |
C | Our After-Sales Department will perform the duties as the agreement |
Product Categories : Block Ice Machine > Direct cooling block ice machine
